Open structure front protection given the low speeds
Open structure rear protection given the low speeds
Right side protection, open structure given the reduced speeds
Left side protection, open structure given the low speeds
Lower floor - machining / Slots for T-nuts upon customer request
Moving table - machining / Slots for T-nuts upon customer request
Installed power 18.5 KW
Main cylinder thrust force 370 Tons
Sheet metal pressing cylinder thrust force
Horizontal light on operator side 2050 mm
Vertical span 1500 mm
Main cylinder stroke 500 mm
Sheet metal cylinder stroke
Height of the work surface from the ground 900 mm
Lower worktop size 2000x1200 mm
Mobile worktop size 2000x1200 mm
Rapid descent speed 20 mm/sec
Working speed 3 mm/sec
Rapid rise speed 20 mm/sec

Front protection light curtains
Rear protection, closed structure with opening gate
Closed structure right side protection
Left side protection, closed structure
Lower floor - machining / Slots for T-nuts upon customer request
Moving table - machining / Slots for T-nuts upon customer request
Installed power 12.5 KW
Main cylinder thrust force 70 Tons
Sheet metal pressing cylinder thrust force
Horizontal light on operator side 2,300 mm
Vertical span 700 mm
Main cylinder stroke 500 mm
Sheet metal cylinder stroke
Height of the work surface from the ground 900 mm
Lower worktop size 2200x950 mm
Mobile worktop size 2200x950 mm
Rapid descent speed 100 mm/sec
Working speed 3 mm/sec
Rapid rise speed 100 mm/sec

Front protection photoelectric barriers
Fixed screwed casing rear protection
Right side protection fixed screwed casing
Left side protection fixed screwed casing
Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 11 KW
Main cylinder thrust force 20 Tons
Operator side horizontal light 1000 mm
Side horizontal light 700 mm
Vertical light 890 mm
Main cylinder stroke 550 mm
Height of the worktop from the ground 930 mm
Lower worktop size 1000x700 mm
Mobile worktop size 1000x700 mm
Fast descent speed 200 mm / sec
Working speed 5 mm / sec
Fast ascent speed 200 mm / sec

- POWER 150TON
- LIGHT BETWEEN THE 1000MM SHOULDER
- DEPTH OF THE PLAN 1.000MM
- LIGHT BETWEEN OPEN PLANS 400MM
- STROKE 400MM
- DESCENT SPEED 10MM / SEC
- WORKING SPEED 2MM / SEC
- RETURN SPEED 10MM / SEC
- CONTROL OF THE PRESS AT MANUAL DISTRIBUTOR + BUTTON
- PRESS EQUIPPED WITH OPTICAL BARRIER ON THE OPERATOR SIDE AND FIXED PROTECTION ON THE NET ON THE OPPOSITE OPERATOR SIDE

- MAIN PISTON PRESS 100TON
- LIGHT BETWEEN THE COLUMNS 810x810mm
- LIGHT BETWEEN THE OPEN PLANS 800mm
- STROKE OF THE PISTON 6000mm
- DESCENT / ASCENT SPEED 100mm / sec
- ADJUSTABLE WORKING SPEED ACCORDING TO THE EFFORT THAT FIND FROM 35 - 10mm / sec
- COMPLETE WITH BLANK HOLDER: POWER 35TON - STROKE 250mm
- PARKER / DENISON BRAND HYDRAULIC SYSTEM
- ELECTRICAL SYSTEM BRAND SIEMENS / PROFACE
- COMPLETE WITH 03 PRESSURE STEPS TO ADJUST THE PRESSURE DOWN / ASCENT FOR THE BLANK
- COMPLETE ALSO WITH A THIRD MECHANICAL EFFECT ADJUSTABLE BY SCREWS PLACED IN THE MOBILE PRESS TOP
- COMPLETE WITH OPTICAL BARRIERS ON THE OPERATOR SIDE, WITH FIXED REAR PROTECTION AND WITH OPENABLE HOUSINGS WITH LIMIT SWITCHES ON THE SIDE SIDES OF THE PRESS

- POWER 350TON
- LIGHT BETWEEN USEFUL COLUMNS 1000x1000mm
- LIGHT BETWEEN OPEN FLOORS 1,400mm
- PISTON STROKE 1.000mm
- DESCENT SPEED 200MM / SEC
- WORKING SPEED 5MM / SEC
- RETURN SPEED 200MM / SEC
- COMPLETE ELECTRONIC INSTRUMENTATION PRESS WITH TOUCH SCREEN BRAND "PROFACE" AND PLC "SIEMENS"
- COMPLETE WITH OPTICAL BARRIERS ON THE LEVEL IV OPERATOR SIDE
- PRESS EQUIPPED WITH 3 WORKING CYCLES: MANUAL, AUTOMATIC, AUTOMATIC WITH ROBOT (ROBOT EXCLUDED FROM THE SUPPLY AEM3)
- HYDRAULIC MATERIAL BRAND DENISON / PARKER
- OVERALL DIMENSIONS 1.700x2.600x5.000mm
- WEIGHT 23.000Kg

- POWER 150TON
- LIGHT BETWEEN THE SHOULDERS 1,250MM
- PLAN DEPTH 1.250MM
- LIGHT BETWEEN OPEN PLANS 400MM
- PISTON STROKE 400MM
- DESCENT SPEED 10MM / SEC
- WORKING SPEED 2MM / SEC
- RETURN SPEED 10MM / SEC
- CONTROL OF THE PRESS WITH MANUAL DISTRIBUTOR + BUTTON
- PRESS EQUIPPED WITH FIXED PROTECTION ON THE NET ON THE OPPOSITE SIDE

- POWER 100TON
- LIGHT BETWEEN SHOULDERS 1050MM
- LIGHT BETWEEN THE SIDE SHOULDERS 400MM
- WORKTOP HEIGHT WELDED FROM THE GROUND 800MM
- PISTON STROKE 500MM
- LIGHT BETWEEN OPEN FLOORS 600MM
- MOBILE PLAN AND FIXED PLAN OF 1000x600MM EQUIPPED WITH N ° 02 “T” SLOTS OF M16 IN LONGITUDINAL
- DESCENT SPEED 60MM / SEC
- WORKING SPEED 5MM / SEC
- RETURN SPEED 60MM / SEC
- ELECTRICAL SYSTEM WITH TOUCH SCREEN BRAND "ESA" AND PLC BRAND "SCHNEIDER / TELEMECANIQUE"
- COMPLETE WITH OPTICAL BARRIERS OF LEVEL IV ON THE OPERATOR SIDE AND WITH FIXED PROTECTION ON THE NET ON THE REMAINING PRESS SIDES

- 200 TONN POWER distributed on 3 hydraulic cylinders
- LIGHT between the OPERATOR SIDE MOUNTS mm. 1,550
- LATERAL LIGHT between the MONTANTI mm. 450X450
- VERTICAL LIGHT between OPEN WORKTOPS mm. 400
- WORKTOP mm. 1500x700
- CYLINDER PRESS RANGE mm. 300
- SPEED CLOSING PRESS mm./sec. 200
- WORKING SPEED PRESS mm./sec. 5
- SPEED OPENING PRESS mm./sec. 200
- WORKTOP HEIGHTS AND MAXIMUM HEIGHT customized for each press

- IDEAL FOR BENDING OF CALL ON TUBES WITH DIAMETER 10 "3/4 (858 mm. WIDTH PLATE) A D.48" (3830 mm. WIDTH PLATE) AND THICKNESS UP TO 60 mm. THIS ALLOWS YOU TO FOLD THE PRINCIPLE OF WORKING HALF THE TIME
- PRESS "COLUMNS 4"
- POWER 3000 ton. (N° 2 CYLINDERS 1500 ton. / CAD)
- LIGHT BETWEEN THE COLUMNS 4100X600 mm.
- LIGHT BETWEEN PLANS OPEN 1500 mm.
- STROKE OF HYDRAULIC CYLINDER 450 mm.
- SPEED 'DOWN / UP 200 mm/sec.
- SPEED 'MAX POWER AT WORK 10 mm/sec.
- VALVES EQUIPPED WITH CONTROL OF THE PRESS TO LEARNING SYSTEM AND FULL OF SAVING RECIPES, CYCLES TOTAL, PARTIAL CYCLES.

- FOUR COLUMN PRESS
- POWER 1000 ton.
- SPAN 2200x2200x1500 mm.
- STROKE 1000 mm.
- SPEED 200/10/200 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION
- COMPLETE WITH 200TON UPPER BLANK HOLDER STROKE 250 mm.
- COMPLETE WITH 400 ton. LOWER BLANK HOLDER STROKE 500 mm. WITH FOUR 100 ton. LATERAL SHOCK ABSORBERS STROKE 300 mm.
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.

- “PILLAR” PRESS - POWER 1200 ton.
- SPAN 3800x2000x2500 mm.
- STROKE 1200 mm.
- ELECTRONIC WORKING SPEED REGULATION
- COMPLETE WITH 400 ton. UPPER BLANK HOLDER STROKE 250 mm.
- COMPLETE WITH 400 ton. LOWER BLANK HOLDER STROKE 500 mm.
- WITH FOUR 100 ton. LATERAL SHOCK ABSORBERS STROKE 300 mm.
- COMPLETE WITH EXTERNALLY SLIDING BOLSTER TO CHANGE MOULDS UPPER AND LOWER SURFACE EQUIPPED WITH 240 HOLES FOR 50 mm. DIAMETER ELECTRODES
- “FIAT” AND “GERMAN” SPACING METHODSv- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES MOULD SPOTTING PRESSES.

- “4 COLUMN” PRESS - POWER 600 ton - SPAN 2500X700X1200 mm.
- STROKE 700 mm.
- SPEED 200/7-15/200 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION
- COMPLETE WITH 300 ton
- BLANK HOLDER STROKE 400 mm. WITH 60 HOLES FOR 40 DIAMETER ELECTRODES
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND ON THE BACK SIDE AND WITH FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL
- PRESSES WITH HEATED MOULDS.

- “4 COLUMN” PRESS
- POWER 120 ton
- SPAN 1200X700X450 mm.
- STROKE 400 mm.
- SPEED 200/10/200 mm/sec.
- EQUIPMENT WITH PROPORTIONAL SOLENOID VALVE WITH THREE MANUFACTURING CYCLES: MANUAL, SEMIAUTOMATIC, AUTOMATIC AND WITH BIMANUAL PUSH-BUTTON CONTROL PANEL
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES.

- LAMIERE/PLATE/SHEET MOULDING PRESS
- “4 COLUMN” PRESS
- POWER 100 ton
- SPAN 1200x1000x1100 mm.
- STROKE 600 mm.
- SPEED 250/15-2/250 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION
- COMPLETE WITH 60 ton BLANK HOLDER STROKE 250 mm. AND WITH 16 HOLES FOR 40 mm. DIAMETER ELECTRODES
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES
- BIMANUAL PUSH-BUTTON CONTROL PANEL.

- “4 COLUMN” PRESS
- POWER 200 ton
- SPAN 1520x1520x800 mm.
- STROKE 500 mm.
- SPEED 28/3/28 mm/sec.
- COMPLETE WITH 70 ton BLANK HOLDER STROKE 150 mm. AND WITH 30 HOLES FOR 40 mm. DIAMETER ELECTRODES
- EQUIPMENT WITH PROPORTIONAL SOLENOID VALVE WITH THREE MANUFACTURING CYCLES: MANUAL, SEMIAUTOMATIC, AUTOMATIC AND WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.

- “4 COLUMN” PRESS
- POWER 60 ton
- SPAN 2000x1000x1300 mm.
- STROKE 700 mm.
- SPEED 200/8/200 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION WITH SELF-LEARNING EQUIPMENT, DATA STORAGE AND OTHER ACCESSORIES
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL.

- “4 COLUMN” PRESS
- POWER 100 ton
- SPAN 2500x1350x2000 mm.
- STROKE 1250 mm.
- SPEED 400/15/400 mm/sec.
- ELECTRONIC WORKING SPEED REGULATION
- SELF-LEARNING EQUIPMENT WITH DATA STORAGE AND OTHER ACCESSORIES WITH BIMANUAL PUSH-BUTTON CONTROL PANEL
- LEVEL IV PROTECTION BARRIERS ON THE OPERATOR’S SIDE AND ON THE OPERATOR’S BACK SIDE AND WITH FIXED WIRE MESH PROTECTION ON THE REMAINING PRESS’S SIDES.
