Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 3 KW
Thrust force of main cylinder 100 Tons
Operator side horizontal light 1050 mm
Vertical light 1000 mm
Main cylinder stroke 300 mm
Rapid descent speed 20 mm / sec
Working speed 3 mm / sec
Rapid rise speed 20 mm / sec

Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 11.5 KW
Thrust force of main cylinder 300 Tons
Operator side horizontal light 1050 mm
Vertical light 220/1300 mm
Main cylinder stroke 500 mm
Rapid descent speed 10 mm / sec
Working speed 3 mm / sec
Rapid ascent speed 10 mm / sec

Lower floor - machining / slots for T nuts on customer request
Movable table - machining / slots for T nuts at the customer's request
Installed power 4 KW
Thrust force of main cylinder 100 Tons
Operator side horizontal light 2050 mm
Vertical light 400 mm
Main cylinder stroke 300 mm
Height of the worktop from the ground 900 mm
Lower worktop size 2000x1200 mm
Mobile worktop size 2000x1200 mm
Rapid descent speed 28 mm / sec
Working speed 3 mm / sec
Rapid rise speed 28 mm / sec

- PRESS 100TON
- OPERATOR SIDE LIGHT 1050MM
- SIDE LIGHT 400MM
- STROKE 300MM
- APPROXIMATE SPEED 10MM / SEC
- WORKING SPEED 3MM / SEC
- ELECTRONIC DISTRIBUTOR CONTROL WITH TWO-HAND PUSH-BUTTON CONTROL

- STANDARD PRESS FOR 150TON LIGHT 1520MM ART. 945 / B
THIS PRESS IS COMPLETE WITH BLADE HOLDER, BLADE AND PRISM ABLE TO FOLD SHEETS UP TO 10MM THICKNESS UP TO 1.5MT LENGTH AND IT IS EQUIPPED WITH ELECTRIC SELF-LEVELING SYSTEM WITH POSSIBILITY TO SET HIGH / LOW PRESSURE AND PRESSURE.

- THIS "FIXED PISTON" PRESS HAS THE FOLLOWING CHARACTERISTICS:
- POWER 200TON
- LIGHT BETWEEN THE SHOULDERS ON THE OPERATOR SIDE 1520MM
- 510MM LIGHT BETWEEN THE SIDE SHOULDERS
- LIGHT BETWEEN PISTON AND PALLET ALL RETURNED 1000MM
- 500MM PISTON STROKE
- COMPLETE WITH HYDRAULIC LIFTING OF THE PALLET WITH CONTROL THROUGH SELECTOR PLACED ON THE ELECTRICAL PANEL
- APPROXIMATE PRESS WEIGHT 5.500Kg
- OVERALL DIMENSIONS 2,500x1,500x3,800mm

- POWER 200TON
- LIGHT BETWEEN THE SHOULDERS 2050MM
- LIGHT BETWEEN THE SIDE SHOULDERS 800MM
- LIGHT BETWEEN MOBILE AND PALLET WITH ALL MOUNTED 600MM
- PISTON STROKE 500MM
- COMPLETE WITH HYDRAULIC LIFTING OF THE PALLET WITH CONTROL PLACED ON THE ELECTRICAL PANEL
- ELECTRICAL SYSTEM WITH ELECTRONIC INSTRUMENTATION WITH TOUCH SCREEN BRAND "PRO-FACE" AND PLC "TELEMECANIQUE / SCHNEIDER"
- DESCENT SPEED 28MM / SEC
- WORKING SPEED 3MM / SEC
- COMPLETE WITH 20 RETRACTABLE BALLS PLACED ON THE TABLE OF THE PALLET TO FACILITATE THE LOADING / UNLOADING OF THEIR PROCESSING EQUIPMENT
- 2000X1000MM MOBILE PLATE AND 2000X1200MM FIXED PLATE WITH "T" CABLE AS PER CUSTOMER REQUEST

- POWER 300TON
- LIGHT BETWEEN THE SHOULDERS ON THE OPERATOR SIDE 2050MM
- LIGHT BETWEEN THE SIDE SHOULDERS 800MM
- LIGHT BETWEEN PISTON AND PALLET ALL RETURNED 1500MM
- PISTON STROKE 500MM
- DESCENT SPEED 28MM / SEC
- WORKING SPEED 2MM / SEC
- RETURN SPEED 28MM / SEC
- CONTROL OF THE PRESS WITH ELECTRIC DISPENSER THROUGH TWO-HAND PUSH BUTTON
- COMPLETE WITH HYDRAULIC LIFTING OF THE PALLET WITH CONTROL BY SELECTOR PLACED ON THE TWO-HAND PUSH BUTTON
- COMPLETE WITH SELECTOR FOR MOVING THE MOTORIZED PISTON RIGHT / LEFT
- CAPACITY OF THE TANK ABOUT 450LT
- ENGINE POWER INSTALLED ABOUT 15kW
- OVERALL DIMENSIONS 3.000X1.600X4.200mm
- APPROXIMATE WEIGHT 12.000Kg

- POWER tonn.300
- LIGHT NET between SHOULDERS mm. 2500
- LIGHT between PLANS OPEN mm. 1000
- STROKE MOBILE PLAN mm. 500
- DISTANCE from LAND of the WORK PLAN mm. 1000
- SPEED CLOSED/OPEN mm./sec. 28
- SPEED WORK ADJUSTABLE mm./sec. 3

Press command manual distributor + button and complete n ° 02 adjustable limit switches in both directions ascent/descent.
Complete even 1000 mm blade. to bend sheets up to a thickness of 10 mm. of ns. standard.
Lifting of the hydraulic pallet distributor via manual lever placed under the electrical panel of the press command.

- WITH THIS KIND OF PRESSES THE PIECE TO BE STRAIGHTENED OUT MAY BE WORKED ON ANY OF ITS PARTS WITHOUT SHIFTING ITS INITIAL POSITION MOVABLE HEAD PRESS WITH POWER-DRIVEN MOVEMENTS
- POWER 300 ton
- 2000x3000x800 mm. WORK TABLE
- STROKE 500 mm.
- 11 Kw ENGINE - PROPORTIONAL SOLENOID VALVE CONTROL WITH THREE MANUFACTURING CYCLES: MANUAL, SEMIAUTOMATIC, AUTOMATIC

- WITH THIS KIND OF PRESSES THE PIECE TO BE STRAIGHTENED OUT MAY BE WORKED ON ANY OF ITS PARTS WITHOUT SHIFTING ITS INITIAL POSITION FLOATING CYLINDER PRESS FOR PLATE
- POWER 200 ton
- 2000x2500x800 mm. WORK TABLE
- STROKE 500 mm.
- 7.5 Kw ENGINE
- PROPORTIONAL SOLENOID VALVE CONTROL WITH THREE MANUFACTURING CYCLES: MANUAL, SEMIAUTOMATIC, AUTOMATIC AND WITH BIMANUAL PUSH-BUTTON “BRIDGE CRANE” CONTROL PANEL
- COMPLETE WITH BARS FOR LIFTING MATERIALS
- WORK TABLE EQUIPPED WITH FOUR “T” SLOTS WITH M20 TRANSVERSALLY AND WITH THE POSSIBILITY OF ADDING A SECOND WORK TABLE SINCE IT IS ALREADY FURNISHED WITH THE NECESSARY HOLES
- COMPLETE WITH LIMIT SWITCH FOR STROKE REGULATION UPSTROKE/DOWN STROKE, RIGHT/LEFT AND FORWARD/BACKWARD.

- WITH THIS KIND OF PRESSES THE PIECE TO BE STRAIGHTENED OUT MAY BE WORKED ON ANY OF ITS PARTS WITHOUT SHIFTING ITS INITIAL POSITION SLIDING CYLINDER PRESS
- POWER 150 ton
- 2000x5000x1200 mm. WORK TABLE
- STROKE 500 mm.
- 7.5 Kw ENGINE
- CONTROL WITH SELF-LEARNING PROPORTIONAL SOLENOID VALVE WITH TWO MANUFACTURING CYCLES: MANUAL, AUTOMATIC AND WITH BIMANUAL PUSH-BUTTON “BRIDGE CRANE” CONTROL PANEL COMPLETE WITH BARS FOR LIFTING MATERIALS
- WORK TABLE EQUIPPED WITH FOUR “T” SLOTS WITH M20 TRANSVERSALLY AND WITH THE POSSIBILITY OF ADDING A THIRD WORK TABLE
- SINCE IT IS ALREADY FURNISHED WITH THE NECESSARY HOLES
- COMPLETE WITH LIMIT SWITCH FOR STROKE REGULATION UPSTROKE/DOWN STROKE, RIGHT/LEFT AND FORWARD/BACKWARD.

- POWER 400 Ton
- FRONT OPENING 2050 mm.
- CYLINDER STROKE 500 mm.

- POWER CYLINDER TOP 100 Tonn
- FRONT OPENING 1050 mm.
- UPPER CYLINDER STROKE 500 mm.
- POWER CYLINDER SHEET METAL AWARDS 10 Tonn
- STROKE CYLINDER SHEET METAL AWARDS 200 mm.

- POWER 500 Ton
- OPEN FRONT 2050 mm.
- CYLINDER STROKE 500 mm.

- Power from 70 Ton to 150 Ton
- Front opening 1050 mm. to 1520 mm.
- Cylinder stroke 300mm. to 400 mm.

- Power from 70 Ton to 150 Ton
- Front opening 1050 mm. to 1520 mm.
- Cylinder stroke 300mm. to 400 mm.

- Power from 100 Ton to 150 Ton
- Front opening 1520 mm. at 2050 mm.
- Cylinder stroke 300mm. to 400 mm.

- Power from 70 Ton to 150 Ton
- Front opening 1050 mm. to 1520 mm.
- Cylinder stroke 300mm. to 400 mm.
- Cylinder manual handling standard flyer.

- Power from 70 Ton to 150 Ton
- Front opening 1050 mm. to 1520 mm.
- Cylinder stroke 300mm. to 400 mm.

- Power from 200 Ton to 300 Ton
- Front opening 1520 mm. at 2050 mm.
- Cylinder stroke 300mm. to 500 mm.

- Power from 200 Ton to 300 Ton
- Front opening 1520 mm. at 2050 mm.
- Cylinder stroke 300mm. to 500 mm.
- Handling standard motorized cylinder.

- Power from 200 Ton to 300 Ton
- Front opening 1520 mm. at 2050 mm.
- Cylinder stroke 300mm. to 500 mm.
